The AGMAX power harrow with seeder is a combination implement that prepares seedbeds. It plants seeds in one pass. It saves time and improves soil structure, resulting in enhanced seed germination.
The power harrow is not a primary tillage implement. As a secondary tillage implement, it should only be used on ground previously broken by ploughing, rotary hoeing, disc harrowing, etc.”
Power harrows don’t invert soil layers, which helps to minimise soil compaction and preserve beneficial soil microbes.
The AGMAX 130cm power harrow with seeder is ideal for small farms and market gardens. Combining soil preparation in one pass not only saves time and fuel, but it also ensures uniform seed depth and spacing.
> Buy AGMAX power harrow with seeder online
The AGMAX power harrow consists of three components:
Power Harrow – consisting of vertical tines driven by the tractor’s PTO. It’s designed to break up soil clumps and level the seedbed.
Seeder Box – mounted on the power harrow, dropping seeds into the prepared soil.
Roller – a wire cage that firms the soil to ensure seed-to-soil contact.
Specifications (With Seeder)
| Model | PHS110 | PHS130 | PHS170 | PHS210 |
| BUY ONLINE | Shop Now | Shop Now | Shop Now | Shop Now |
| Tractor HP | 20-35 | 35-60 | 50-60 | 60-80 |
| Three Point Linkage (TPL) | Cat 1 | Cat 1 or 2 | Cat 1 or 2 | Cat 1 or 2 |
| Working Width | 110cm (3’7″) | 118cm (3’10”) | 165cm (5’5″) | 205cm (6’9″) |
| Overall Width With Wire Roller | 145cm (4’9″) | 144cm (4’9″) | 185cm (6’1″) | 225cm (7’5″) |
| Maximum Depth | 15cm (6″) | 15cm (6″) | 15cm (6″) | 15cm (6″) |
| Blades | 10 | 12 | 16 | 20 |
| Seed Box Capacity (L) | 60L | 100L | 145L | 195L |
| PTO | 540rpm | 540rpm | 540rpm | 540rpm |
| Weight | 300kg | 395kg | 457kg | 540kg |
Specifications (Without Seeder)
| Model | PH110 | PH130 | PH170 | PH210 |
| BUY ONLINE | Shop Now | Shop Now | Shop Now | Shop Now |
| Tractor HP | 20-35 | 28-60 | 50-60 | 60-80 |
| Three Point Linkage (TPL) | Cat 1 | Cat 1 or 2 | Cat 1 or 2 | Cat 1 or 2 |
| Working Width | 110cm (3’7″) | 118cm (3’10”) | 165cm (5’5″) | 205cm (6’9″) |
| Overall Width With Wire Roller | 145cm (4’9″) | 144cm (4’9″) | 185cm (6’1″) | 225cm (7’5″) |
| Maximum Depth | 15cm (6″) | 15cm (6″) | 15cm (6″) | 15cm (6″) |
| Blades | 10 | 12 | 16 | 20 |
| Seed Box Capacity (L) | N/A | N/A | N/A | N/A |
| PTO | 540rpm | 540rpm | 540rpm | 540rpm |
| Weight | 240kg | 300kg | 356kg | 418kg |
Warranty & Support
BEST PRICE – BEST WARRANTY – BEST SUPPORT
Buy direct and save! SOTA is the exclusive importer of AGMAX implements in Australia.
AGMAX implements are fully supported – we carry spare parts for all AGMAX models in stock.
AGMAX implements are warranted for 2 years against failure when properly maintained and operated.
AGMAX power harrows are proven performers. They are widely used in over a dozen European countries, including Germany, Austria, Italy, Spain, Denmark, Switzerland and Ireland.
